OPC PHOTONICS’ High Power Laser Combiner is used to combine several single-mode lasers into one Beam Delivery fiber to achieve laser power output in the range of several kilowatts to 10,000 watts. Visible light source can be added to the output delivery fiber for guidance in the machining process.
We can produce the Nx1 High Power Laser Combiner including 2×1, 3×1, 4×1, 6×1, and 7×1 and so on.
| Features | Applications |
| · High Power Transfer Efficiency
· Low insertion loss · Custom Configurations Available |
· High Power Fiber Laser
· Industry Laser Processing |
Performance Specifications(Typical Configuration)
| Parameters | Values | ||||
| Port Configuration | 3×1 | 4×1 | 5×1 | 6×1 | 7×1 |
| Laser Wavelength | 1020-1000nm | ||||
| Laser Input Fiber | 25/250DCF or 20/400DCF | ||||
| Visible light source fiber type | 6/125 SCF or 10/125 SCF (if need visible light source) | ||||
| Output Fiber | Beam Delivery fiber 50/360 0.2NA, or 100/360 0.2NA | ||||
| Transmission Efficiency | >98% | ||||
| Total Power Handling | 3000W, 5000W, 10,000W | ||||
| Package Dimension | High power module(Air cooling or Water cooling) | ||||
| Operating Temperature | 0~75℃ | ||||
| Storage Temperature | -40~85℃ | ||||
Remark:
- Other configuration and higher power handling can be customized.
- All combiners default with bare fiber, 0.8m length of pigtail, please contacts us for special request.
- Due to ongoing design improvements, the package size is subject to change. According to the different configuration, power handling, and fiber core diameter, we will choose the appropriate package size. Please contact OPC PHOTONICS for confirmation.
*High power device package must be mounted onto heat sink (active cooling is suggested) with thermal paste.
Order information
P/N: HPLC-A-B-C-D-E-F
| A | B | C | D | E |
| Port | Laser Power per Input | Input Fiber Type | Output Fiber Type | Fiber length |
| 3: 3×1
4: 4×1 6: 6×1 61:(6+1)x1 7: 7X1 |
500:500W
1000:1000W 1500:1500W XXXX:Other |
XXX(fiber name) | XXX(fiber name) | 08:0.8m(default)
10:1.0m 20:2.0m |
Part Number Example: HPLC-6-1000-20/400/006/046-100/360/022-10
Description: 6 x 1 High Power Laser Combiner, 1000W per laser power, 20/400µm, 0.065/0.46NA input laser fiber, 100/360µm, 0.22NA output beam delivery fiber, 1.0m fiber length.
