The Polarization Maintaining Isolator &BPF, a two port micro-optic device built with PM panda fiber is a combination of a BPF and an isolator in a compact package. The PM BPF&isolator features low insertion loss, high isolation, high extinction ratio and high reliability and stability. The device guides optical light in one direction and block out unwanted noise signals, eliminates back reflection and back scattering in the reverse direction. The device can be built with bare fiber, or 900um jacket cable. The PM Panda Fiber BPF Isolator is widely used in amplifier systems, fiber optic systems and fiber lasers.

If you do not see a standard BPF&isolator that meet your needs, we welcome the opportunity to review your desired specification and quote a custom isolator. Requests for custom fiber pigtails, different wavelengths and handling power of operation or other specific needs will be readily addressed. OPC PHOTONICS can respond to custom requirements with short lead times.

Features Applications
·        Low Insertion Loss

·        High Extinction Ratio

·        High isolation

·        Excellent stability and reliability

 ·        Fiber laser

·        Fiber amplifier

·        Fiber Sensor

·        Communications

Performance Specifications

Parameter Unit Specification
Stage Single Stage Single Stage Dual Stage
Operating wavelength nm 1030 1064
Min. Pass bandwidth@0.5dB nm 2 6 2 5 8 2 5 8
Min. Stop bandwidth@25dB down nm 6 10 6 12 20 6 12 20
Typ. Insertion Loss at 23℃ dB 3.5 1.8 2.8
Max. Insertion loss at 23℃ dB 4.2 2.3 3.5
Typ. Peak Isolation at 23℃ dB 42 42 55
Min. Isolation at 23℃ dB 28 35 45
Extinction ratio (Type B) dB ≥20
Extinction ratio (Type F) dB ≥22
Return loss (input/output) dB ≥50/50
Fiber Type – Nufern PM980-XP / PM1060L Fiber or other
Max. Power Handling (CW) mW 100 300 100
Max. Peak Power for Pulse kW 1, 5,10
Max. Tensile Load(N) N 5
Operating temperature ℃ -5℃ ~ + 70℃
Storage temperature ℃ -40℃ ~ + 85 ℃
Dimensions mm Ф5.5× L35
“B” for Both axis working, “F” for Fast axis blocking





  1. Above specifications are for device without connector.
  2. For devices with connectors, IL will be 0.3dB higher, RL will be 5dB lower and ER will be 2dB lower. The default connector key is aligned to slow axis. Power transmits through the connector less than 2W.
  3. For this 1030nm Isolator, Due to high IL, it is recommended to use average power of <100mW. If you need higher handle power, please look for our 1064nm High power isolator.

For this 1064nm Isolator, Due to high IL, it is recommended to use average power of <300mW for single stage and <200mW for dual         stage. If you need higher handle power, please look for our 1064nm High power isolator.

  1. If there is pulse application, please be sure to inform us of pulse energy and peak power.

Package Dimension

*Due to ongoing design improvements, the package size is subject to change. Please contact OPC PHOTONICS for confirmation.

Order information   P/N: PMISO&BPF-①-②-③-④-⑤-⑥-⑦-⑧

When you inquire, please provide the correct P/N number according to our ordering information, and attach the appropriate description would be better. If need any connector, we do not recommend choosing a 250μm bare fiber pigtail.

① ② ③ ④ ⑤ ⑥ ⑦ ⑧
Type wavelength Pass bandwidth Power Handling Axis Alignment Pigtail Diameter Fiber Length Connector
S:Single stage 30:1030nm

64:1064nm

XX: Others

 2:2nm

6:6nm

 L: Refer to the above table B:Both axis working

F: Fast axis blocking

 25:250μm bare fiber

90:900μm Loose Fiber

XX: Others

 08:0.8m

10:1.0m

XX: Others

 00:None

FP: FC/PC

FA: FC/APC

XX: Others

Part Number Example #1: PMISO&BPF-S-30-2-L-F-25-10-00

Description: 1030nm Polarization Maintaining single stage Isolator & BPF Hybrid Combination- 100mW, <1kW peak power,2nm Pass bandwidth, Fast axis blocking, and 1.0m PM980-XP fiber length with bare fiber and no connector at all ports.

Part Number Example #2: PMISO&BPF-S-64-2-L-F-25-10-00

Description: 1064nm Polarization Maintaining single stage Isolator&BPF Hybrid Combination- 300mW, <1kW peak power, 2nm pass bandwidth, fast axis blocking, and 1.0m PM980-XP fiber length with bare fiber and no connector at all ports.

Ordering Information for Custom Parts

If you need to customize other specifications, please provide detailed description for your requirement.
